ethernet outdoor cat6 cable 305m

Overview of Fahad Cables Cat6 Outdoor Ethernet Cable

The Fahad Cables ethernet outdoor cat6 cable 305m is designed to meet the demands of robust connectivity solutions in outdoor environments. Manufactured in the United Arab Emirates, this cable is a product of rigorous design and stringent quality control processes, ensuring that it adheres to international standards. The cable features an impressive bandwidth capacity of up to 250 MHz, which facilitates high-speed data transmission and makes it ideal for various applications, including streaming, gaming, and high-data transfer tasks.cat6 outdoor ethernet cable 305m

One of the hallmark features of the Fahad Cables Cat6 Outdoor Ethernet Cable is its robust construction, which includes high-quality materials that protect against environmental factors. The external jacket is made from UV-resistant polyethylene, providing exceptional durability against sun exposure, moisture, and other weather-related challenges. This makes it particularly suitable for outdoor installations, where cables are often exposed to harsh conditions. Furthermore, the cable is designed to resist chemical damage and physical abrasion, ensuring longevity and reliability.

In terms of design, the Cat6 cable consists of eight twisted pairs of wires, which are meticulously arranged to minimize crosstalk and interference. This twisted-pair design is essential for achieving high performance and maintaining signal integrity over longer distances. It supports Power over Ethernet (PoE) applications, allowing the cable to transmit both data and electrical power to devices like IP cameras and wireless access points, thus enhancing utility.

Overall, the Fahad Cables Cat6 Outdoor Ethernet Cable exemplifies advanced engineering, making it an excellent choice for users seeking a reliable solution for outdoor connectivity. Whether for residential or commercial use, this cable promises durability and high performance, ensuring seamless data transmission for a wide range of applications.

ELECTRICAL SPECIFICATIONS
Characteristic Impedance: 100±6 Ohm @ 1-250 MHz
DC Resistance: 93 Ohm/Km max.
Resistance unbalance: 2% max.
Mutual Capacitance: 5.6 nF/100m Max. @ 1 KHz
Cap. Unbalance (wire to ground): 1600 pF/m max. @ 1 KHz.
Voltage rating: 72 Vdc max.
Dielectric strength: 1500 Volts/1 minute min rms
Velocity of Propagation (NVP): 67-69%
Propagation Delay Skew: 514 + 36/vf. nS/100m max @ 1-300 MHz
Insulation Resistance: 5000 Mega Ohm•Km min. @ 500 Vdc
Coupling attenuation: 40 dB min @ 30-100 MHz 40-20Log(f/100) @100-300 MHz

PHYSICAL AND MECHANICAL PROPERTIES
Basic Conductor: bare copper
Conductor Size: 23AWG
Insulation: HDPE
Number of insulated conductors: 8, twisted in 4 pairs
Color Code of Pairs: Blue x White/Blue, Orange x White/Orange, Green x White/Green, Brown x White/Brown
Overall Coverage: N
Drain wire: N
Outer Jacket: PVC+ Heavy-duty, black, UV-resistant PE compound for outdoor use.
Standard Jacket Color:Black
Standard Surface Marking: Includes fci P/N, cable description, Meter mark and Model Number
Pulling force: 110 N max.
Short Term Bend Radius: 8xOD (mm)
Temperature operating range: -20 to +80C
Installation temperature range: 0 to +50C
Ordering Information
Item Name: Cat6 dj utp 6xxx6m PE+PVC Outdoor Cable 23 awg 4 pair 305m
