fiber optic pigtail single mode lc-apc simplex lszh 1 meter

د.إ 2.50

General Specification:

Connector : LC

Polish Type : APC

Fiber Mode : 9/125um

Fiber Grade : ITU-TG.652D, G.657A1 /A2

Wavelength : SM:1310/1550nm

Cable Diameter : 0.9mm

Insertion loss : ≤0.3 dB

Return loss :≥60 dB

Durability : >1000 Times

Minimum Bend Radius : 30 mm

Jacket Material : LSZH

Color : Yellow

Model No. : FCI-3362

Products ID : P52201

Description

FAHAD CABLES single mode lc/apc simplex fiber optic pigtail lszh 1 meter

FAHAD CABLES fiber optic pigtail single mode lc-apc simplex lszh 1 meter High Quality and Cost-effective SM,MM Simplex Fiber Patch Cord Patch Cords are used to provide optical connection for fiber optic electronics. The use of the patch cord provides a quick and easy method for routing fiber. fiber optic pigtail single mode lc-apc simplex lszh 1 meter

FAHAD CABLES Patch cables are manufactured and tested in compliance with TIA 604 (FOCIS), IEC 61754 and YD/T industry standards. OM1, OM2, OM3, OM4,
OM5 or OS2 fiber types to meet the demand of Gigabit Ethernet, 10 Gigabit Ethernet and high speed Fiber Channel. Every termination through rigorous. parameter test to ensure the highest in network performance. Fahad Cables Industry R Provide Local Manufacturing Facility for Fiber Optic Accessories Patch cord and Pigtail. at UAE, With Made in UAE Coo.

Optical Specifications

  • Mode type: Single mode / multi mode
  • Cable Type: Simplex/Duplex
  • Connector Style: SC, FC, ST, LC, MTRJ,
  • Polish Type: PC,UPC,APC
  • Diameter: 0.9mm, 1.6mm, 2.0mm, 3.0mm
  • Lengths: 1,2,3,4,5,8,10,15,20,25,30,40,50,70,100Meter
  • Strength Member: Aramid Yarn
  • Outer Jacket: LSZH/PVC/OFNR/OFNP
  • Interchangeability &Vibration: ≤0.2dB
  • Minimum Bend radius: 10 -13mm
  • Wavelength: SM:1310/1550nm MM:850nm
  • Operating temperature: -40~75°C
  • Jacket Color
  • Single mode: Yellow / Green, Yellow Blue
  • Storage temperature: -45~85°C
  • Multi mode: OM-1, OM-2 (Orange/Beige ) ,OM-3,(Aqua) OM-4 (Purple)
  • Fiber type: ITU-T G.652D, G.657A1 /A2

PHYSICAL AND MECHANICAL PROPERTIES

Mode type Single-mode
Cable TypeSimplex
Connector StyleSC-SC
 Fiber Type ITU-T G.652D
Polish typeAPC
Diameter 2.0mm
Outer Jacket LSZH
Insertion loss ≤0.3dB
Return loss ≥60dB
WavelengthSM,1310/1550nm
Length1Meter
Ordering Information
Model NoItem CodeDescription
FCI-3401S51101Y fiber optic patch cord single mode sc-sc-apc simplex lszh 1meter
